| Technical Specification | Unit | MHZ1540 | MHZ1560 |
| Max. jointing length | mm | 4000 | 6200 |
| Max. jointing width | mm | 130 | 130 |
| Max. jointing thickness | mm | 75 | 75 |
| Max. jointing force | kg.f | 6000 | 6000 |
| Saw blade diameter | mm | ?305 | ?305 |
| Saw spindle speed | r/min | 3550 | 3550 |
| Sawing motor power | kW | 2.2 | 2.2 |
| Hydraulic pump motor power | kW | 3 | 3 |
| Air source pressure | MPa | 0.6- 0.8 | 0.6- 0.8 |
| Hydraulic rated pressure | MPa | 10 | 10 |
| Power | V/Hz | 380/50 | 380/50 |
| Overall dimensions | mm | 6021×1253×1490 | 8021×1253×1490 |
|
Net.weight |
kg |
2000 | 2160 |
